| Physical Features |
Properties |
Test Results |
| Thickness |
2.0 mm |
| Size |
610 x 610 mm |
| Weight / m² |
2.0 mm : 3.24 kg/m² |
| Dimension Stability EN434 |
0.01% |
| Flexibility ASTM F137 |
Dia 8mm : Pass |
| Squareness SJ/T 11236-2001 |
610 x 610 : ± 0.02mm |
| Residual Indentation SJ/T 11236-2001 |
≤ 0.15 mm |
| Abrasion Resistance ASTM D4060
(CS- 1000g, 1000 cycles) |
0.0987 g |
| Hardness ASTM D2240 |
65 (Type D / 1 sec) |
| Static Load Limit ASTM F-970 |
0.02mm |
| Electrical Features |
Electrical Resistance ANSI/ ESD S7.1 - 2005 |
1 x 10 6 < R < 10 8 Ω |
| Body Voltage Generation SJ/T 11236-2001 |
IVI < 100 volt |
| Static Decay GJB2605-1996 |
≤ 2 sec |
| Resistance To Chemical |
Resistance to Chemical ASTM F925 |
Good
(Test results available upon request) |
| Fire Resistance |
Smoke Generated ASTM E662-6/ NFPA 258 |
450 or less |
| Critical Radiant Flux ASTM E648-06a/ NFPA 253 |
Class I |
| Flame Spread ASTM E 84-07/ NFPA 255 |
Class II |
| Outgassing ASTM E 595 |
Excellent ( Test Result available) |
| Miscellane- ous Features |
Color Fastness ISO 105 B02 |
≤ 6 |
| Water Proof Test ASTM D570 |
0.19% |
