General Information

Design
EOS 1 is a small thermal transfer printers with high production speed. EOS1 is a printer for Partex PPQ+ and ProSleeve and several other Partex products. The printer is connected to the computer via a USB 2.0 port and controlled by Partex software. It is also compatible with other software, such as NiceLabel label.

• Small table printer for high demand production of wire, cable and component marking.
• Feeds and prints Partex profiles and labels.
• Cost effective identification system for use in panel building and electrical installations.

FACTS

• Thermal transfer printing : 300 dpi print resolution.
• Printing speed : 125 mm/s.
• PC connection USB 2.0 connection and Partex software WinSign.
• Power supply : 100 - 240V (50-60Hz).
• Power consumption : max 300 W.
• CE : certified.
• Measurements : 189x322x253mm (H x W x D)
• Weight : 4.0 Kg
• Operation data : Operating temperature: +5°C till +40°C
• Humidity : 10 - 85 % not condensing, To obtain the best printing result, the temperature of the profile shouldn’t be lower then +25°C.
